    2 / 4 Ports FXO FXS VoIP ATA, Call Terminal, VoIP Gateway, FXO to SIP Converter

    Ask Lasest Price
    Brand Name : Biocare or OEM
    Model Number : BVG04
    Certification : CE FCC
    Price : USD 60-130 per unit
    Payment Terms : T/T, Western Union, MoneyGram
    • Product Details
    • Company Profile

    2 / 4 Ports FXO FXS VoIP ATA, Call Terminal, VoIP Gateway, FXO to SIP Converter


    Introduction

    BVG04 is a multi-purpose VoIP gateway product series designed with the needs of service providers and enterprises in mind.
    With BVG04 VoIP SIP gateways, service providers can provide telephony and fax services to subscribers using many access methods such as FTTB, HFC, and ADSL. Enterprises can use the BVG04 for IP PBX phone solutions, and the interconnection of multiple sites like PABXs.
    BVG04 can also serve as a remote SIP terminal for IP-PBX solutions

    Main Applications:
    ? Residential telephone service or IP-centrex with IMS platform
    ? Local or remote VoIP access gateways for IP PBX,Call center
    ? Interconnection for PABXs, or Lines extension;
    ? VoIP Long Distance application


    Key Features:

    ? SIP or MGCP VoIP analog phone adapter
    ? SIP to PSTN analog VoIP ATA adapter
    ? Support IMS TISPAN Specs
    ? TR069 for Management
    ? RADIUS Client for CDR
    ? High Speed Fax

    Specification

    VoIP SpecsProtocols: SIP and MGCP
    Voice Codecs: G.711u/aLaw, G.729A
    DTMF Method: RFC2833, SIP INFO, In-Band
    G.168 Echo Cancellation
    T.38 fax relay, T.30 fax transparent
    VAD: Voice Active detection
    CNG: Comfort noise generation
    Dynamic jitter buffer management Static jitter buffer
    QoS: IEEE 802.1p tag
    DiffServ code point (TOS) bits
    Encryption for RTP and SIP packages
    NetworkDHCP Client
    PPPoE Client
    DNS/DDNS
    NAT traversal (STUN)
    VLAN
    FTP/HTTP
    FXS PortsDialing support both of DTMF and Pulse
    Polarity inverse generation
    Caller ID generation (FSK/DTMF, before ring and after ring)
    Ring cadence setting
    Ring frequency setting
    Volume control
    Hook flash timing setting
    Message waiting indicator (FSK, polarity inverse)
    FXO PortsPolarity inverse detection
    Caller ID detection (FSK/DTMF, before ring and after ring)
    Busy tone detection
    DTMF out-pulsing timing setting
    Volume control
    Ring timing setting
    Automatic attendant (2nd stage dialing)
    Direct inward dialing DID
    Busyout
    Call FeaturesBlind/Explicit transfer
    Call forward
    Call Waiting
    Caller ID by number or name
    Caller ID blocking
    Caller ID on call waiting
    Distinctive ring
    Do not disturb
    Music on hold
    Color ring back tone
    Call progress tone (Configurable)
    Release control (Called party control, calling party control)
    Three-way calling
    Speed dialing
    Calling and called number based routing
    Call number transformation (Add, delete, replace)
    Hunt group (Sequential and circular hunt)
    Ring group
    Digit map
    PSTN failover
    Peer to Peer calls without SIP server
    Intercom PBX function
    ManagementTR069-based management (Include TR069, TR104, and TR106)
    SNMP MIB V2
    Auto-Provision
    Web-based management interface (Local and remote access)
    Configuration files import and export by WEB
    System status monitoring and statistics by WEB
    Syslog
    OthersProcessor: ATMEL AT91SAM9G20
    DSP: TI TMS320VC5509A
    System Memory: 32M
    Flash Memory: 8M
    FXO/FXS Connector: RJ11
    Off-hook Detection: Loop start or DDI
    Max. User Line Length 1500 meters
    Ring Voltage: 60V 20 RMS
    OnHook Voltage: -48V
    Ring Equivalent Value 5 REN (short distance)
    Power supply 12V/1A
    Power Consumption 12W
    Dimension (H x W x D) 150 x 109 x 30 mm
    Weight: Net weight: 0.4Kg; Gross weight (include package): 0.5Kg
    Operating Temperature: 0~40 ºC; Humidity: 10%~90% (non conducing)
    Non Operating Temperature: -10~60 ºC; Humidity: 5%~90% ( non conducing )
