asterisk gsm gateway terminal,GOIP16, 16 ports 64 sim gsm gateway

Ask Lasest Price
Brand Name :	Biocare or OEM
Model Number :	GOIP8
Certification :	CE FCC
Price :	USD 300-1000 per unit
Payment Terms :	T/T, Western Union, MoneyGram
Supply Ability :	5000 per month

Add to Cart

Product Details
Company Profile

asterisk gsm gateway terminal,GOIP16, 16 ports 64 sim gsm gateway

16 ports GSM voip gateway with 64 sim card

Key features:
Support 8 / 16 channels with 8-64 sim cards
Support 850/900/1800/1900MHz quad-band GSM network
Support BTS and carrier change and locked
Support IMEI and PIN modify
SMS receiving/batch sending, AT command compatible
Support USSD balance enquiry
Automatically lock/switch SIM card according to its balance, balance alarm

Introduction:

The GSM VoIP gateway is a wireless Phone Gateway that support 8/16 channels CDMA interface with 8-64 sim card. GSM Gateway is a new product that connect the GSM and the VOIP seamlessly. To GSM Gateway what is installed on the Mobile SIM Card, you can register the GSM telephone on the VOIP Softswitch.SIP and H.323 agreement are built in the GSM Gateway and configured flexible.
Caller ID can be seen by using SIP. Flexible routing can meet the need of all kinds of call forwarding; even more special is that GSM GATEWAY support multi-device group, it can be easily combined into arbitrary number of channels of Large Gateway Group.

Basic features:
Support SIP registration and peer-to-peer
Support Hotline, Phone book, Speed dial, Dial Plan
Update firmware by local or internet
Field proven compatible with Asterisk-based softswitches
Single-channel debug for manual calling, directly AT command
LCR automatically route calls
Centralized network management
Caller ID detection and generation
Master and slave SIP server
VLan and QoS support
SIM card hot plug
Calling Statistics
Support customized IVR

Mobile Features:
SMS Send, Receive and Forward(GSM/SIP/HTTP)
SMS Inbox
AT Command
USSD
SMS Format: PDU/TXT
PIN Code Management
GSM Polarity Reversal
Carrier Selection
Caller ID Hidden(need SIM Card support)

Specifications

Model	Goip16-64 16 channels with 64 sim cards
Network	GSM
Frequency	850/900/1800/1900MHz
Call Control Protocols	SIP
Voice Codecs	G.729A, G.723.1, G.711 a/ulaw
Network Protocols	IPv4, TCP, UDP, PPPoE, DHCP, DNS, NAT, Telnet, HTTP, FTP, TFTP
Configuration and Maintenance	Web-based GUI Console, Telnet command line Centralized network management
Firmware Update	Local file, FTP, TFTP and HTTP
Telephony Features	Hot-line call ,Dial plan, Speed dial, Phone book, CDR, LCR, White list
Telephony Signaling	DTMF tone dectection/generation DTMF relay: in-band, RFC 2833 and SIP info Call forward: unconditional, no answer and busy N-way conferencing Caller ID display/generation, Mobile Number Portability
Voice Quality	Echo cancellation Silence suppression(voice activity detection, comfortable noise generation) Adaptive jitter buffer
Number of Ports	1 WAN 10/100Base-T ethernet(RJ-45 connector) 1 LAN 10/100Base-T ethernet(RJ-45 connector) 1 console(RJ-11 connector)
LEDs	1 power and 8 groups of signal strength and running indicator
Power Supply	100-240VAC, 50 - 60 Hz
Dimensions	Rack mountable 1U chassis(compatible with 19" Rack) Width: 482mm Height: 44mm Depth: 210mm
Weight	2.5kg
Operating Environment	·Operating temperature: 0 - 50ºC ·Operating humidity: 10 - 90%
Warranty	12 Months
