    HST-U30-K5 Series Premium Video PTZ Cameras Specification Sheet

    Ask Lasest Price
    Model Number : 7-3
    Price : $325.00/Pieces >=1 Pieces
    • Product Details
    • Company Profile

    HST-U30-K5 Series Premium Video PTZ Cameras Specification Sheet

    HST-U30-K5 Series Premium Video PTZ Cameras Specification Sheet
    HST-U30-K5 Series Premium Video PTZ Cameras Specification Sheet
    HST-U30-K5 Series Premium Video PTZ Cameras Specification Sheet
    USB3.0 Cable connect to PC
    HST-U30-K5 Series Premium Video PTZ Cameras Specification Sheet
    USB 3.0 PTZ Camera is equipped with 20x Optical zoom, 12V 2A Power supply, it outputs HD Video and supports PTZ movement Control. 2.1 Megapixel Effective CMOS Sensor achieved 1080p@30 high quality images. USB 3.0 ideally suits Medium sized conference rooms, it can be connected with any Web Conferencing system in Windows and MAC OS. Features:  PRO PTZ Camera design  OSD Menu/Lens Menu  Speed Match  UVC Protocol 1.5  IR remote controller unit  USB 3.0 Connection Performance:  1920x1080pixels progressive @30fps  20x optical zoom  HOV 58.7 degree  1/2.8”Progressive CMOS Sensor  355 degree Pan movement  Tilt +90 degree, - 45 degree  64 preset positions  4 cruise lines  No need Power adaptor Dimension: L 250 mm x W 140 mm x H 160 mm Installation:  Desktop  Standard Tripod  Wall mount  Ceiling mount Remote control unit
    1)Reset 2)Power ON/OFF 3)IR Select 4)PAN, TILT, Home position 5)AUTO, MANUAL, FAR, NEAR 6)Zoom in/out 7)DOME OSD, LENS OSD 8)REV 9)SET/CLEAR/CALL Presets 10)1-9 Presets

    Accessories List: 1)HD PTZ Camera 2)3 meters USB 3.0 Cable 3)Ceiling mount bracket 4)Installation kits package 5)Power supply 6)User’s manual book 7)IR remote control
    Specification Sheet

    Model number:
    HD8820-U30-K5
    20 x




    Image Sensor
    Sensor
    1/2.8'' Progressive CMOS
    Effective pixel
    2.1 Megapixel
    Minimum Scene
    illumination

    0.5Lux at F1.6
    White balance
    MANUAL/AUTO/ATW/INDOOR/OUTDOOR
    Gain Control
    AUTO
    Back-light
    compensation
    On/Off
    S/N Ratio
    >50db
    IRIS
    F1.6—F3.5

    Lens
    Focus
    f=4.7-94 mm
    Zoom
    20x Optical Zoom
    Hov
    58.7 degree
    Video Output
    USB 3.0 Type B
    Video format
    USB3.0:1080P30/25(YUY2)、720P30/25(YUY2)、800×600、640×480
    Control Interface
    USB
    PTZ Control Protocol
    VISCA, PELCO-D, UVC
    Baud Rate
    9600/38400bps
    Patrol tours
    4
    Preset
    64
    OSD Menu
    Support
    Speed Matching Function
    Support
    Image Auto Flip
    Support
    Pan Speed
    0-100 degrees/s
    Tilt Speed
    0-100 degrees/s
    Pan Rotation Angle
    0-355 degree
    Tilt Rotation Angle
    + 90, - 45 degree
    Auto Pan Scan
    Support
    Remoter Control
    IR Wireless remote control P/T/Z
    Power
    DC12V±10%,2A
    Operation Temperature
    0℃~50℃
    Environmental humidity
    0-95%RH(non-condensaion)
    Length X width X high
    L 145 mm x W 148 mm x H 160 mm
    Weight
    1450 g
    Company Profile
    HST-U30-K5 Series Premium Video PTZ Cameras Specification Sheet
    Opaxy is a high-tech company working on digital audio & video and communication technology, and is committed to offer one-stop solution for customer through sales of and service on multimedia communication, optical fiber communication, network communication products and service. Being focused on customer’s need and continuous development, we developed series of products, including matrixes, video processors, signal converters & extenders, digital cameras, PCM, PDH. These products are widely used in television system, highway, transportation, army, petrochemical industry, airport, school, building, etc. And Opaxy also have abundant experience on project construction, have completed many projects of surveillance, video transmission etc. in these industries. Aiming at becoming the best equipment and project designing & construction supplier, here are our main advantages: To offer products very competitive on price, quality and timing;
    With more than ten years’ experience, the specialized team can offer professional advice on projects; We can vary products based on customer’s need with fast response, to best serve our customer; Our network with partners in the industries enables us to access to whole series of products, to offer you one-stop solution; Offer original entrusted manufacturing. We are willing to work with customers from all over the world and supply you our best products and service.
